APC® Back-UPS® ES 650VA Battery Backup Item # 660678
Share
-
Email This Page
- Note: You can share Individual Items, entire Shopping Carts, and Shopping Lists.
-
Share this Item
Close
Print
660678
was removed.
Thank you, you will now be redirected to comparisons.
Just a moment while we prepare the page
Check In-Store Availability
Description
Protects your computer and peripherals from damaging spikes, surges and power outages
- Lets you save your work and safely power down.
- High-efficiency design helps to conserve power, saving you money on your electric bill!
- Includes 8 outlets — all with surge protection, 4 that provide battery back-up.
- Features surge protection for your telephone/Ethernet line as well.
Product Details
| Item # | 660678 |
| OfficeMax # | 24007780 |
| Manufacturer # | BE650G1 |
| Load Capacity (Watt) | 390 W |
| Backup/Run Time (Full Load) | 3 Minute |
| Maximum Battery Recharge Time | 24 Hour |
| coaxial cable line protection | yes |
| height | 3.4 in |
| Certifications & Standards | CSA C22.2 No. 107.1; FCC Part 15 Class B; FCC Part 68; NOM; TUV-C; UL 1778; UL 1449 |
| number of outlets with battery backup | 4 |
| Output Voltage | 120 V AC |
| standalone/rack-mounted | standalone |
| battery type | Lead Acid |
| protection status indication | yes |
| width | 7.1 in |
| Product Line | Back-UPS |
| assembly required | No |
| package contents | Back-UPS 650 VA Desktop UPS; USB Cable; User Manual |
| average charging time | 16 hours |
| depth | 11.2 in |
| Product Name | Back-UPS 650 VA Desktop UPS |
| EMI/RFI noise reduction | yes |
| manufacturer | American Power Conversion |
| postconsumer recycled content | 0% |
| cord length | 5 feet |
| Plug/Connector Type | NEMA 5-15P |
| weight | 13.64 lb |
| Eco-conscious | No |
| brand name | APC |
| connected equipment warranty | $75,000 |
| UL listed | yes |
| USB | Yes |
| volt-amps | 650 VA |
| Input Connectors | 1 x power NEMA 5-15 |
| Frequency Provided | 60 Hz |
| Input Voltage | 110 V AC |
| Battery Characteristics | Maintenance-free, Sealed, Spill-proof |
| Backup/Run Time (Half Load) | 12 Minute |
| dimensions | 5.3"H x 15.3"W x 9"D |
| Dataline Protection | RJ-45 |
| Load Capacity (VA) | 650 VA |
| joule rating | 340 joules |
| fax/phone line protection | yes |
| total recycled content | 0% |
| wattage | 390 watts |
| form factor | Desktop |
| number of outlets | 8 |
| Receptacles | 4 x NEMA 5-15R |
| color | black |
| on/off switch | yes |
| warranty length | 3-year limited |
| mounting hardware included | no |
| model name | BE650G1 |
| hot swappable | Yes |
| Show More ▾ |
Customer Reviews
Rated 4.7 out of 5�by 23
reviewers.
Rated 5 out of 5�by IT_Joe Great Product
Great product with lots of nice features. A great product for the price. The only issue I have with these is that they seemed to have shortened the USB management cable. They used to be about a foot longer which makes a difference in my particular office. In the future I hope they lengthen the USB cable.
March 2, 2016
Rated 5 out of 5�by chamaco A great product and value
Y recently replaced my oldest APC 350U UPC with a nex APC 650 Backup unit to protect my computer and aaditional equipment
October 14, 2015
Rated 5 out of 5�by Josh Excellent Investment
Well-priced, quality protection for your electronics. I will be buying additional units as I upgrade my current protection.
September 22, 2015
Rated 5 out of 5�by jsyjack Great Product
Overall a great product. Been using APC for many years, both at home and at a large metropolitan data center. APC systems have kept me going on several occasions.
Wouldn't own or run computers without them!!!
Only complaint on the current APC Back-UPS 650, is that they dropped the RS-232 connector.
Also, the support staff is always very helpful.
February 3, 2015
Product Q & A
(1 Q�:�1 A)
Product Q&A
Ask your questions. Share your answers.
Our Backup is about 5 years old and it is time to replace the battery. I can't determine which replacement battery is correct.
1 year, 9 months ago
by
SADO
Answers
Answer:�
The correct replacement battery cartridge for this unit, model BE650G1, is the RBC17.1 year, 9 months ago
by
APCProductSupport
1 of 1
1 of 1
From the Manufacturer|
APC Back-UPS® BE650G1 Video
Overview
-
Back-UPS BE650G1
- Guaranteed protection and battery backup power for your valuable electronics, ensuring they remain safe from dangerous power disturbances
- Stay available and connected by powering critical devices (computers, wireless networking devices, gaming consoles, security systems and other electronics) during a blackout
- 8 total outlets – 4 battery backup, 4 surge only outlets, 2 transformer block spaced
- PowerChute software provides safe system shutdown, preventing potential data corruption
- Guaranteed protection from surges and spikes caused by storms, lightning, circuit overloads, power cycling, etc.
- Periodic battery self-test ensures early detection of a battery that needs to be replaced
- Lifetime $75,000 equipment protection policy for all connected electronics
- ENERGY STAR® certified
Product Features
-
Backup Power for Important Devices
The electronic devices you rely on every day for communication, security, and entertainment such as networking equipment, computers, televisions, security systems, and gaming consoles are at risk of damage and disconnect due to unexpected blackouts, voltage fluctuations, and other power disruptions.
The APC by Schneider Electric Back-UPS BE650G1 provides instant battery power to your critical electronics when the power goes out, keeping you connected and available both personally and professionally. Additionally, the BE650G1 UPS (uninterruptible power supply) offers guaranteed surge and lightning protection for attached devices. By connecting your valuable devices, you are ensuring these investments against potentially irreversible damage. When the power goes out, the APC BE650G1 will power critical devices including home networking equipment; allowing you to maintain your internet connection. This allows you to work productively, avoid the loss of valuable data, and safely shut down equipment.
This BE650G1 includes PowerChute Personal Edition software which provides UPS management options, safe system shutdown, and energy monitoring to enable cost savings and prevent potential data corruption. The BE650G1 also offers eight surge protected outlets, four of which provide UPS battery backup, and a 390-watt/650-volt ampere output power capacity.Battery Backup Keeps Critical Components Running
The BE650G1 UPS offers guaranteed backup battery power for your electronic devices. When power is interrupted or fluctuates outside safe levels, the BE650G1 instantly provides clean battery power to your sensitive electronics. Work safely throughout brief outages or save your data and safely shut down electronics during extended outages. -
Protection from Dangerous Surges and Spikes
The BE650G1 features a total of eight power outlets, all of which shield your devices against dangerous surges and spikes in voltage. Four of these are UPS battery backup outlets that provide instant power to critical devices like computers and home networking equipment when there is an outage. -
Prevent Data Corruption with PowerChute Software
APC PowerChute Personal Edition power and energy management software is included. PowerChute prevents data corruption by automatically saving files and shutting down your system in an extended power outage or low-battery condition. PowerChute monitors and displays energy usage and reduces costs via customized energy management planning. Connect the USB cable that's included with your UPS backup unit to your computer to easily use the software.
Phone and Network Data Line Surge Protection
In addition to standard power line surge protection, the BE650G1 also provides protection from dangerous "backdoor" surges that travel along telephone and network data lines. Just route the phone or network data line through the BE650G1 UPS to protect your devices from lightning, surges, and spikes. -
ENERGY STAR Certified for Energy Efficiency
The BE650G1 UPS is ENERGY STAR® certified for its efficient operation and ability to help realize lower energy costs.
-
Warranty and Equipment Protection Policy
This UPS is covered by a three-year limited warranty. It also comes with a lifetime equipment protection policy of up to $75,000. APC will repair or replace attached equipment that sustains surge-related damage while properly connected to a registered Back-UPS uninterruptible power supply unit. -
Package Contents
APC Back-UPS BE650G1 with 6-foot power cord, PowerChute Personal Edition software CD, USB cable, and user manual.
Back-UPS Product Selector
Technical Specifications
-
Output
- Output Power Capacity: 390 Watts / 650 VA
- Max Configurable Power: 390 Watts / 0 VA
- Nominal Ouput Voltage: 120V
- Outpout Frequency (sync to mains): 50/60Hz +/- 3Hz
- Topology: Standby
- Waveform Type: Stepped approximation to a sinewave
- Output Connections: (4) NEMA 5-15R (Battery Backup), (4) NEMA 5-15R (Surge Protection)
-
Input
- Nominal Input Voltage: 120V
- Input Frequency: 50/60Hz +/- 3Hz (auto sensing)
- Input Connections: NEMA 5-15P
- Cord Length: 1.52 meters
- Input Voltage Range for Main Operations: 90 - 140V
-
Batteries & Runtime
- Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
- Typical Recharge Time1 : 24 hour(s)
- RBC Quantity: 1
-
Communications & Management
- Interface Port(s): USB
- Control Panel: LED status display with On Line : On Battery : Replace Battery and Building Wiring Fault
- Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
-
Surge Protection & Filtering
- Surge Energy Rating: 340 Joules
- Filtering: Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
- Data Line Protection: RJ45 10/100 Base-T Ethernet protection
-
Physical
- Maximum Height: 3.46 in
- Maximum Width: 7.09 in
- Maximum Depth: 11.89 in
- Net Weight: 13.64 lbs
- Shipping Weight: 15.40 lbs
- Shipping Height: 5.04 in
- Shipping Width: 9.25 in
- Shipping Depth: 15.47 in
- Color: Black
-
Conformance
- Regulatory Approvals: California (CEC) Battery Charger, CSA C22.2 No. 107.1, ENERGY STAR (USA), FCC Part 15 Class B, FCC Part 68, NOM, TUV-C, UL 1778
-
Sustainable Offer Status
- oHS: Compliant
- REACH: Contains no SVCHCs
Images
Back-UPS Comparison
|
|
|
|
|
| APC Back-UPS® BE350G | APC Back-UPS® BE550G | APC Back-UPS® BE650G1 | APC Back-UPS® BE750G | |
|---|---|---|---|---|
| Output | ||||
| Output Capacity | 350 VA / 210 W | 550 VA / 330 W | 650 VA / 390 W | 750 VA / 450 W |
| Output-on utility | 120V, 50 or 60 Hz, +/- 3Hz (auto sensing) | 120V, 50 or 60 Hz, +/- 3Hz (auto sensing) | 120V, 50 or 60 Hz, +/- 3Hz (auto sensing) | 120V, 50 or 60 Hz, +/- 3Hz (auto sensing) |
| Output-on battery | 115V +/-8%, 50 or 60 Hz +/-1 Hz (auto sensing) | 115V +/-8%, 50 or 60 Hz +/-1 Hz (auto sensing) | 115V +/-8%, 50 or 60 Hz +/-1 Hz (auto sensing) | 115V +/-8%, 50 or 60 Hz +/-1 Hz (auto sensing) |
| Output Connections |
6 total NEMA 5-15R: 3 battery & surge 3 surge only |
8 total NEMA 5-15R outlets: 4 battery backup & surge 4 surge protection only |
8 total NEMA 5-15R outlets: 4 battery backup & surge 4 surge protection only |
10 total NEMA 5-15R: 5 battery & surge 5 surge only (incl. 3 Controlled outlets) |
| Waveform Type | Stepped Approximation to Sine Wave | Stepped Approximation to Sine Wave | Stepped Approximation to Sine Wave | Stepped Approximation to Sine Wave |
| Input | ||||
| Input Volt., Freq | 120V, 50 or 60 Hz, +/- 3Hz | 120V, 50 or 60 Hz, +/- 3Hz | 120V, 50 or 60 Hz, +/- 3Hz | 120V, 50 or 60 Hz, +/- 3Hz |
| Input Conn. | 5 ft cord with right angle plug (NEMA 5-15P) | 5 ft cord with right angle plug (NEMA 5-15P) | 6 ft cord with right angle plug (NEMA 5-15P) | 6 ft cord with right angle plug (NEMA 5-15P) |
| Surge Protection | ||||
| AC Power | All outlets protected | All outlets protected | All outlets protected | All outlets protected |
| Data Line | Analog phone line, RJ-11 (Fax, modem, DSL) | Analog phone line, RJ-11 (Fax, modem, DSL) |
Analog phone line, RJ-45 (Fax/Modem/DSL) Network line, RJ-45 (Ethernet 10/100 Base-T) Coax cable (Cable Modem/TV/DSS) |
Analog phone line, RJ-45 (Fax/Modem/DSL) Network line, RJ-45 (Ethernet 10/100 Base-T) Coax cable (Cable Modem/TV/DSS) |
| Physical | ||||
| Unit Dims H x W x D | 3.5” x 6.25” x 11.0” | 3.5“ x 12.0” x 7.0” | 3.54“ x 12.6” x 6.97” | 13.5" x 7.1" x 3.5" |
| Unit Weight | 8.0 lbs | 13.0 lbs | 14.3 lbs | 10.34 lbs |
| Battery | ||||
| Battery Type | Sealed, lead-acid, maintenance-free | Sealed, lead-acid, maintenance-free | Sealed, lead-acid, maintenance-free | |
| External Battery Compatibility | Not compatible | Not compatible | Not compatible | Not compatible |
| Management | ||||
| Alarms | Visual (LED status indicators) and audible alarms | Visual (LED status indicators) and audible alarms | Visual (LED status indicators) and audible alarms | Visual (LED status indicators) and audible alarms |
| Shutdown S/W | none | Compatible with PowerChute Personal Edition (via USB interface) | Compatible with PowerChute Personal Edition (via USB interface) | Compatible with PowerChute Personal Edition (via USB interface) |
| Safety | ||||
| Certification/ Approvals |
FCC Part 15 Class B, FCC Part 68, UL1778, NOM, TUV, UL 497A, UL 498 |
FCC Part 15 Class B, FCC Part 68, UL 1778, TUV |
FCC Part 15 Class B, FCC Part 68, UL1778, TUV |
FCC Part 15 Class B, FCC Part 68, UL1778, NOM, TUV, CSA C22.2 No.107.1, |
- 1 The time to recharge to 90% of full battery capacity following a discharge to shutdown using a load rated for 1/2 the full load rating of the UPS.
